Akupanel FR | Custom 1x0.25
Akupanel FR | Custom 1x0.25
Akupanel FR | Custom 1x0.25
Akupanel FR | Custom 1x0.25

Akupanel FR | Custom 1x0.25

  • Class A fire-rated acoustic panel
  • Narrow-slat design for subtle rhythm
  • 23.58″ × 96″ size, 22 mm thickness
  • Multiple core and veneer/laminate options
Request quote Request Sample
Akupanel FR Custom Options
Akupanel FR | Custom 3x1

Design with confidence

  • Fast shipping
  • Made in the USA
  • Sustainable materials
  • Trusted by architects

Resources & Technical Information

Technical documentation, finish specifications, and additional information are available in our Resources section.

→ Go to Resources ( Akupanel 1x0.25 )

Looking for a refined acoustic solution for smaller spaces? The Akupanel FR 1x0.25 offers a subtle, elegant rhythm with narrow slats that won’t overpower your design. This fire-rated acoustic panel provides both high performance and aesthetic versatility for commercial and architectural interiors.

Composition & Finish

Akupanel FR 1x0.25 is available with any Resonance Acoustic base color, ForesColor or MDF middle layer, and your choice of natural wood veneer, high-pressure laminate (HPL), or phenolic-backed metal laminate facing. Panels can also be produced using Lab Design Laminates for additional design options.

Specifications

Size

Panel size: 23.58” x 96” (598 mm x 2440 mm)
Thickness: 22 mm (0.866”)

Fire Rating
PET backer: Flame Spread Index 0 / Smoke Developed Index 350
Black MDF core: Flame Spread Index 15 / Smoke Developed Index 5
Complies with Class A fire rating standards (Flame Spread Index 0–25, Smoke Developed Index 0–450)

Size

────

23.58” × 96” (598 × 2440 mm)

Thickness

────

22 mm (0.866”)

Fire rating

────

Class A (ASTM E84 / UL 723)

Construction

────

Acoustic core with veneer, HPL, or metal laminate facing

Akupanel FR 1x0.25

Looking for a refined acoustic solution for smaller spaces? The Akupanel FR 1x0.25 offers a subtle, elegant rhythm with narrow slats that won’t overpower your design. This fire-rated acoustic panel provides both high performance and aesthetic versatility for commercial and architectural interiors.

Resources & Technical Information

Access technical documentation, finish specifications, and supporting materials to assist with planning, specification, and project development.
